Production Details
| Model: | ECO-6073D1-2 | Panel thickness: | 0.45mm ss |
| body thickness: | 0.45mm painting | Valve: | φ0.7mm*2 |
| Power: | 2.2kW*2(320 g/h)+1000W | Electric stove: | 155mm |
| Air ducts: | φ16mm*1.0 | Burner: | Steel burner with enamel fire cap |
| Product size: | 600*280*90mm,3.2KG | Pipe: | φ16mm*0.7 |
| Package: | 3layer color box + 5layer carton box + One-page manuals | Carton: | 635*95*345mm,3.9KG,1pcs/CTN |
| 20GP/40 HQ: | 1345pcs/3267pcs | Volume: | 0.021 |
PRODUCT CUSTOMIZATION PROCESS:
✔ Select Style
✔ Product Offer
✔ Effects Design
✔ Confirmation Sample
✔ Produce to order
✔ Payment and shipment
Customized optation:
☑️Logo color options: White/Gray/Red/Blue/Yellow and so on
☑️Stove options:
☑️Knob options:
☑️Pan support:Enameled wire rack
☑️Nozzle (determines the type of gas used)
NG nozzles : LPG nozzles
☑️Adapter: A3 iron connector
☑️Stove Feet:
☑️Stove Stand:
IMPORTANT SAFEGUARDS:
1.Be careful to avoid getting burned by touching the top panel of the gas table as it gets very hot near the burner when in use.
2. Do not apply excessive pressure to the gas control knobs.
3. To avoid damage, do not place charcoal on the burners.
4. Do not allow the holes in the burners to become clogged.
5. Keep the gas table clean for better service and a longer operation life.
6.At night and when leaving the house, be sure to turn off not only the control knobs of the gas table, but also the main gas valve of gas bottle as well.
7. For better complete combustion, keep the burners clean.
8. Check the rubber gas hose which connect the gas cooker to the gas bottle regularly for wear or leak, it must be replaced occasionally. Keep it away from heat source and keep it clean.
9. Make sure that there are no inflammable objects near the gas table.
